Installation
Installation accessories
Operating Instructions – MOVIDRIVE
®
modular
50
Standard accessories – electrical accessories
Designation Power supply module Single-axis module Double-axis
module
Master
module
0100
(BG1)
0100
(BG1A)
0250 0500,
0750
0020,
0040,
0080,
0120
0160,
0240
0320,
0480
0640,
1000
0020,
0040
0020,
0040,
0080
+24V supply voltage
2×
Designation Power supply module Single-axis module Double-axis module Master
module
0100
(BG1)
0100
(BG1A)
0250 0500,
0750
0020,
0040,
0080,
0120
0160,
0240
0320,
0480
0640,
1000
0020,
0040
0020,
0040,
0080
DC link connection,
PE connection
3× 1×
Designation Power supply module Single-axis module Double-axis module
0100
(BG1)
0100
(BG1A)
0250 0500,
0750
0020,
0040,
0080,
0120
0160,
0240
0320,
0480
0640,
1000
0020, 0040 0020,
0040, 0080
8-pole module bus cable,
system bus EtherCAT
®
/
SBus
PLUS
1×
Designation Power supply module Single-axis module Double-axis module
0100
(BG1)
0100
(BG1A)
0250 0500,
0750
0020,
0040,
0080,
0120
0160,
0240
0320,
0480
0640,
1000
0020, 0040 0020,
0040, 0080
DC link closing cover
2×
Designation Power supply module Single-axis module
MDP90A-0250-.. MDA90A-0480-..
Power connection closing cover
1×
The electrical accessories can be ordered with the following part numbers:
Module Part number
Accessory pack
1)
Module bus cable
MDP90A.- power supply module
0100 (BG1): 28224876 18166989
0100 (BG1A): 28225201 18167004
0250: 28230027 18166989
0500, 0750: 28232992 18167012
1100: 28234324
MDA90A-. single-axis module
0020, 0040, 0080, 0120: 28223764 18166989
0160, 0240: 28220463 18166997
0320, 0480: 28225236 18167004
0640: 28226178
0640, 1000: 28231643 18167012
1400, 1800: 28233212
MDD90A- double-axis module
0020, 0040 (BG1): 28223764 18166989
0020, 0040, 0080 (BG2): 28220463 18166997
Master module UHX45A/MDM90A 28244397 18166989
1) Accessory pack contains module bus cable
