Technical Data
Technical data of the cards
Operating Instructions – MOVIDRIVE
®
modular
236
Sensor supply
F-SS0, F-SS1 Value/description
Properties
• DC24V output according to EN61131-2
• Short circuit and overload protection
• No electrical isolation
Rated current 150mA
Inrush current (≤10ms) 300mA
Short-circuit protection 180mA
Internal voltage drop <DC1.3V
Pulsed voltage supply (if ac-
tivated)
• 1.9ms–2.1ms open (LOW)
• Period duration, pulsed voltage supply: 7.5ms–
8.5ms
Permitted cable length 30 m (per sensor)
Leakage current (F-SSx
blocked)
< 0.1mA
Safe digital outputs
F-DO00_P/M, F-DO01_P/M Value/description
Properties
• DC24V output according to EN61131-2
• Short circuit and overload protection
Rated current 150mA
Inrush current (≤10ms) 300mA
Leakage current (F-DOx
blocked)
< 0.1mA
Maximum switching fre-
quency
10Hz
Overload protection 210mA
Minimum current for wire
break monitoring
15mA
Permitted cable length 30m
Load capacitance (max. test
pulse duration)
≤300nF
Load capacitance (1ms test
pulse duration)
50 nF
Capacitance to GND/PE
(sourcing output only)
≤10nF
Load capacitance with diode
decoupling
≤12µF
Load inductance ≤100µH
Load inductance with free-
wheeling diode
≤40H
Minimum load resistance >130Ω
