MX-M264U TROUBLESHOOTING 7 – 6
H4 00 Fusing section low temperature trouble (TH_UM) PCU 
01 Fusing section low temperature trouble (TH_US) PCU 
H5 01 5-time continuous jams of POD1, POD2, or PPD2 PCU 
L1 00 Scanner feed trouble SCU 
L3 00 Scanner return trouble SCU 
L4 01 Main motor lock trouble PCU 
11 Shift motor trouble PCU 
30 MFP fan motor trouble MFP 
31 Paper exit cooling fan trouble PCU 
32 Power source cooling fan trouble PCU 
35 Fusing cooling fan trouble PCU 
43 Paper exit cooling fan 2 trouble PCU 
44 Power cooling fan 2 trouble PCU 
56 Fusing cooling fan 2 trouble PCU 
L6 10 Polygon motor trouble PCU 
L8 01 Full wave signal detection error PCU 
02 Full wave signal width abnormality PCU 
20 Power controller communication trouble MFP 
P1 00 PCI communication error MFP 
01 PCI fan error MFP 
02 Plasma generating device error MFP 
PC - Personal counter not detected MFP 
U1 01 Battery trouble MFP 
U2 00 MFP EEPROM read/write error MFP 
05 SD/MFPC PWB SRAM contents inconsistency MFP 
10 MFPC PWB SRAM user authentication index check sum error MFP 
11 MFPC PWB EEPROM counter check sum error MFP 
24 MFPC PWB SRAM memory user authentication counter check sum error MFP 
30 MFPC PWB and PCU PWB manufacturing No. data inconsistency MFP 
40 SD card system storage data area error MFP 
41 HDD system storage data area error MFP 
42 Machine adjustment data (system storage data area) error MFP 
50 HDD user authentication data check sum error
(SD card when no HDD is installed)
MFP 
60 Watermark check error MFP 
80 SCU PWB EEPROM read/write error SCU 
81 SCU PWB EEPROM check sum error SCU 
90 PCU PWB EEPROM read/write error PCU 
91 PCU PWB EEPROM check sum error PCU 
U7 50 MFPC PWB - Vendor machine communication error MFP 
51 Vendor machine error MFP 
UC 02 CPT - ASIC error SCU 
20 DOCC ASIC error SCU 
Trouble
code
Trouble content
Trouble
detection
Mechanism Option Electricity FAX Supply
Main
code
Sub
code

Sharp MX-M264N Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed	26 ppm
Max Print Resolution	600 x 600 dpi
Standard Paper Capacity	1100 sheets
Max Paper Capacity	2100 sheets
Automatic Duplexing	Yes
ADF Capacity	100 sheets
Scan Resolution	600 x 600 dpi
Copy Speed	26 cpm
Copy Resolution	600 x 600 dpi
Connectivity	Ethernet, USB
