MX-M264U VARIOUS STORAGE DATA HANDLING 11 – 4
2. Necessary steps when replacing the PWB, HDD and the SD Card
A. MFP substrate replacement procedure (work flow)
CAUTION: Registered user information will not be recovered if the MFP PWB is affected by U2-05 trouble. (*1)
1) Attach the flash ROM, the memory, the EEPROM, the SD card etc. of the MFP PWB on the service parts MFP PWB and install it to the
main unit.
CAUTION: Ground your body with grounding band during the work.
2) When U2 trouble occurs, use SIM16 to cancel it.
3) Set as follows after restarting the main unit.
At this timing, F6-21 may occur. Whether it may occur or not, go to execute procedure 1.
(1) Set the appropriate country code by Sim66-02 (clear the software switches related to FAX).
CAUTION: Make sure to execute even if the fax option is not installed on the machine.
B. Procedures necessary for HDD replacement
Note for HDD replacement
• Data of the following list are saved in the HDD of the complex machine. If the HDD operates normally and data backup is possible before
replacement, perform data backup and then replace the HDD.
• If the HDD does not operate normally, data cannot be backed up.
• The HDD replacement procedures with a broken HDD differs from that with a normal HDD.
Contents of this chapter
• HDD storage data and backup
• Replacement procedures when HDD storage data can be backed up
• Replacement procedures when HDD storage data cannot be backed up due to breakdown of HDD
• Reinstall and update procedures of Operation Manual data saved in HDD
• Reinstall and update procedures of watermark data.
(1) HDD storage data and backup
Some HDD storage data can be backed up, and some other data cannot. Some HDD storage data can be reinstalled, and some other storage
data cannot.
If the HDD operates normally before replacement and data can be backed up, back up the data before replacement of the HDD referring to the
HDD storage data list. Then reinstall the data after replacement of the HDD.
a. HDD storage data list
*1: The e-Manual cannot be backed up, but can be reinstalled by using Sim49-3 and USB memory.
*2: Watermark data cannot be backed up, but can be reinstalled by using Sim49-5 and USB memory.
No. Data kind
Before installation
(When shipping
from the factory)
After installation
(After use by
users)
Enable/
Disable of
data backup
Backup means
Enable/
Disable of
data reinstall
Data reinstall
procedures
Reinstall
operator
1 e-Manual Available Available Disable *1 Enable Sim49-3 Service
2 Address book Not available Available Enable Sim56-2 /
Device cloning /
Storage backup
Enable Sim56-2 /
Device cloning /
Storage backup
Service
3 Image send series
registration data (Sender’s
information, meta data, etc.)
Not available Available Enable Sim56-2 /
Device cloning /
Storage backup
Enable Sim56-2 /
Device cloning /
Storage backup
Service
4 User authentication
Account management
Not available Available Enable Sim56-2 Enable Sim56-2 Service
5 Japanese FEP dictionary
(Learning)
Not available Available Disable Not available Disable —
6 Chinese FEP dictionary
(Learning)
Not available Available Disable Not available Disable —
7 JOB LOG Not available Available Enable Perform with
WEB PAGE.
Disable —
8 JOB completion list Not available Available Disable Not available Disable —
9 New N/A (FSS) information Not available Available Disable Not available Disable —
10 User font (Added) Not available Available Disable Not available Enable Perform with
WEB PAGE.
Service
or User
11 User macro Not available Available Disable Not available Enable Perform with
WEB PAGE.
12 Document filing Not available Available Enable Perform with
WEB PAGE.
Enable Perform with
WEB PAGE.
13 Some of system setting
data
Not available Available Enable Sim56-2 /
Device cloning /
Storage backup
Enable Sim56-2 /
Device cloning /
Storage backup
Service
14 Watermark Available Available Disable *2 Enable Sim49-5 Service
15 FAX reception data Not available Available Enable Sim66-62 Disable — —
