MX-M264U TOOL LIST 14 – 1

MX-M264U

Service Manual

[14] TOOL LIST

Name Part code Note

Color copy test chart UKOG-0326FCZZ/UKOG-0326FC11

SIT chart UKOG-0280FCZZ/UKOG-0280FCZ1

Gray test chart UKOG-0162FCZZ

Color image density sensor calibration jig UKOG-0318FCZZ

Kynar powder UKOG-0123FCZZ For transfer belt

Grease (HANARL FL-955R) UKOG-0299FCZZ

Conduction grease (FLOIL GE-676) UKOG-0012QSZZ Other shaft

Grease (FLOIL G-313S) UKOG-0307FCZZ

Grease (JFE552) UKOG-0235FCZZ

Stearic acid powder UKOG-0312FCZZ OPC drum

Grease (FLOIL GP-501MR) UKOG-0013QSZZ RSPF paper feed roller shaft

Grease (MOLYKOTE X5-6020) UKOG-0158FCZZ

Grease (MOLYKOTE BR-2 Plus) UKOG-0097FCZZ
