MX-M264U VARIOUS STORAGE DATA HANDLING 11 – 2
C. SD card partition
Option HDD installed
SD card size = 4GB (Actual size 3.6GB)
Option HDD uninstalled
SD card size = 8GB (Actual size 7.2GB)
D. SD card data contents
Option HDD installed
No. File system Stored data NOTE
L-101 Not available ICU firmware (Boot/Main)
Boot animation
Boot (CN Update mode)
ARM9 firmware
lang.sfu (language data)
graph.sfu (Animation data)
S-101 Universal font
web help
spdl
Option FontROM
S-102 Universal Same as above (Mirror)
S-105 Universal Setting value data file (System setting/SIM setting data (Image quality adjustment)/FAX Soft SW)
S-103 Universal Key operator setting storage data
FEP leaning data (Japanese/Chinese)
Firmware update data (differential between new and old) (For FSS)
Account management information/User authentication data
I-101 Image data FAX/Internet Fax receive images (for backup) (HDD 1-4 area data backup)
0 100
0
1
2
3
200 300 400 500 600 700 800 900
[MB]
[GB]
[L-101] 500MB
[S-102] 500MB
[I-101] 1GB
[S-103] 924MB
[S-101] 500MB
[S-105]
100MB
[MB]
0
1
2
3
4
5
6
7
[GB]
200 300 400 500 600 700 800 9000 100
[S-103] 924MB
[S-104]
200MB
[I-101] 500MB [I-102] 500MB
[L-101] 500MB [S-101] 200MB [S-102] 200MB
[S-105]
100MB
[I-103] 4GB
