MX-M264U TROUBLESHOOTING 7 – 23
2. JAM and troubleshooting
A. JAM code list
(1) Main unit
(2) Finisher
(3) RSPF
JAM code JAM content
NO_JAM_CAUSE No JAM. Also used for JAM canceling.
TRAY1 Cassette 1 paper feed JAM
(C1PFD not-reached JAM)
C1PFD_S1 C1PFD remaining JAM (Cassette 1 feed paper)
TRAY2 Cassette 2 paper feed JAM
(C2PFD not-reached JAM)
C2PFD_N3 C2PFD not-reached JAM (Cassette 3 feed paper)
C2PFD_N4 C2PFD not-reached JAM (Cassette 4 feed paper)
C2PFD_S2 C2PFD remaining JAM (Cassette 2 feed paper)
C2PFD_S3 C2PFD remaining JAM (Cassette 3 feed paper)
C2PFD_S4 C2PFD remaining JAM (Cassette 4 feed paper)
TRAY3 Cassette 3 paper feed JAM
(C3PFD not-reached JAM)
C3PFD_N4 C3PFD not-reached JAM (Cassette 4 feed paper)
C3PFD_S3 C3PFD remaining JAM (Cassette 3 feed paper)
C3PFD_S4 C3PFD remaining JAM (Cassette 4 feed paper)
TRAY4 Cassette 4 paper feed JAM
(C4PFD not-reached JAM)
C4PFD_S4 C4PFD remaining JAM (Cassette 4 feed paper)
MFT Manual feed tray paper feed JAM
(PPD1 not-reached)
PPD1_N2 PPD1 not-reached JAM (Cassette 2 feed paper)
PPD1_N3 PPD1 not-reached JAM (Cassette 3 feed paper)
PPD1_N4 PPD1 not-reached JAM (Cassette 4 feed paper)
PPD1_NA PPD1 not-reached JAM (ADU refeed paper)
PPD1_SM PPD1 remaining JAM (Manual feed tray feed paper)
PPD1_S2 PPD1 remaining JAM (Cassette 2 feed paper)
PPD1_S3 PPD1 remaining JAM (Cassette 3 feed paper)
PPD1_S4 PPD1 remaining JAM (Cassette 4 feed paper)
PPD1_SA PPD1 remaining JAM (ADU refeed paper)
POSD_N POSD not-reached JAM
POSD_S POSD remaining JAM
POD1_N POD1 not-reached JAM
POD1_S POD1 remaining JAM
POD2_N POD2 not-reached JAM
POD2_S POD2 remaining JAM
POD3_N POD3 not-reached JAM
POD3_S POD3 remaining JAM
APPD1_N APPD1 not-reached JAM
APPD1_S APPD1 remaining JAM
DRUM Drum lock detection
FUSER Fuser winding detection
PRI_JAM Image preparation wait timeout
FIN_ERR Finisher communication abnormality detection
MTR_ILG Motor driver trouble JAM
SIZE_ILG Size illegal JAM
STOP_JAM Emergency stop request JAM (Controller request)
NO_MATCH Parameter no matching
JAM code JAM content
FPPD1_N Finisher inlet port not-reached JAM
FPPD1_S Finisher inlet port remaining JAM
FIN_TIME Finisher paper early reaching JAM
FSTPD_S Finisher paper exit remaining JAM
FSTPL Finisher staple JAM
FPRD_N Finisher compiler not-reached JAM
FPRD_S Finisher compiler remaining JAM
JAM code JAM content
SPPD1_N SPPD1 not-reached JAM
SPPD1_S SPPD1 remaining JAM
SPPD2_N SPPD2 not-reached JAM
SPPD2_S SPPD2 remaining JAM
SPPD3_N SPPD3 not-reached JAM
SPPD3_S SPPD3 remaining JAM
SPPD4_N SPPD4 not-reached JAM
SPPD4_S SPPD4 remaining JAM
SPPD5_N SPPD5 not-reached JAM
SPPD5_S SPPD5 remaining JAM
SPSD_SCN Exposure start notification timer end
SPPD2_NR SPPD2 reverse not-reached JAM
SPPD2_SR SPPD2 reverse remaining JAM
P_SHORT Short size JAM
SDFS_S Overlap feed detection jam/accompanied feed jam
ICU_REQ ICU factor stop JAM
