Sharp MX-M264N Service Manual

MX-M264U TROUBLESHOOTING 7 – 14
H4-00 Fusing section low temperature
trouble (TH_UM)
H4-01 Fusing section low temperature
trouble (TH_US)
H5-01 5-time continuous jams of POD1,
POD2, or PPD2
L1-00 Scanner feed trouble
L3-00 Scanner return trouble
Trouble content The fusing temperature does not reach the specified
level within the specified time from turning ON the
power relay.
Detail PCU
Cause Main thermistor trouble.
Main heater lamp trouble.
PCU PWB trouble.
Thermostat trouble.
Connector, harness connection trouble.
HL control PWB trouble.
Power unit trouble.
Check & Remedy Use SIM14 to cancel the trouble.
Use SIM44-14 to check the state of the thermistor.
Use SIM5-2 to check the flashing operation of the
heater lamp.
Replace the thermistor.
Replace the heater lamp.
Replace the PCU PWB.
Replace the thermostat.
Check connection of the connector and the harness.
Replace the HL control PWB.
Replace the power unit.
Trouble content The fusing temperature does not reach the specified
level within the specified time from turning ON the
power relay.
Detail PCU
Cause Sub thermistor trouble.
Sub heater lamp trouble.
PCU PWB trouble.
Thermostat trouble.
Connector, harness connection trouble.
HL control PWB trouble.
Power unit trouble.
Check & Remedy Use SIM14 to cancel the trouble.
Use SIM44-14 to check the state of the thermistor.
Use SIM5-2 to check the flashing operation of the
heater lamp.
Replace the thermistor.
Replace the heater lamp.
Replace the PCU PWB.
Replace the thermostat.
Check connection of the connector and the harness.
Replace the HL control PWB.
Replace the power unit.
Trouble content
Detail PCU
Cause A fusing jam is not canceled completely. (A jam paper
remains.)
POD1/POD2/PPD2 sensor trouble
Fusing unit installation trouble
POD1/POD2/PPD2 sensor connector and harness
connection trouble
PCU PWB trouble
Fusing unit, drive section trouble
Check & Remedy Replace the POD1/POD2/PPD2 sensor.
Check installation of the fusing unit.
Replace the fusing unit.
Check paper around the fusing unit section.
Check connection of the POD1/POD2/PPD2 sensor
connector and the harness.
Replace the PCU PWB.
Use SIM14 to cancel the trouble.
Trouble content Scanner feed is not completed within the specified
time.
Detail SCU
Cause Scanner unit trouble.
SCU PWB trouble.
Scanner control PWB trouble.
Harness and connector connection trouble.
Scanner home position sensor trouble.
Scanner motor trouble.
Check & Remedy Use SIM1-1 to check the scan operation.
Replace the scanner unit.
Replace the SCU PWB.
Check connection of the connectors and the harness.
Replace the scanner home position sensor.
Replace the scanner motor.
Trouble content Scanner return is not completed within the specified
time.
Detail SCU
Cause Scanner unit trouble
SCU PWB trouble
Scanner control PWB trouble
Harness and connector connection trouble
Scanner home position sensor trouble
Scanner motor trouble
Check & Remedy Use SIM1-1 to check the scan operation.
Replace the scanner unit.
Replace the SCU PWB.
Check connection of the connectors and the harness.
Replace the scanner home position sensor.
Replace the scanner motor.

Sharp MX-M264N Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed	26 ppm
Max Print Resolution	600 x 600 dpi
Standard Paper Capacity	1100 sheets
Max Paper Capacity	2100 sheets
Automatic Duplexing	Yes
ADF Capacity	100 sheets
Scan Resolution	600 x 600 dpi
Copy Speed	26 cpm
Copy Resolution	600 x 600 dpi
Connectivity	Ethernet, USB
