Sharp MX-M264N Service Manual

MX-M264U VARIOUS STORAGE DATA HANDLING 11 – 9
3. HDD/SD card SIM format operation
The relations between SIM62/66 and formatted (deleted) data are as follows:
*1: Physical format ("0" is written to the all area.)
*2: Logical format (Only the management area is initialized.)
*3: Nothing is done.
SIM66-10 FAX image memory clear
HDD
SD Card
SIM62-1 Hard disk format
HDD
SD Card
SIM62-8 Hard disk format (Excluding the system area)
HDD
SD Card
SIM62-10 Job complete list (Job log data) delete
HDD
SD Card
Partition
number
Partition
I-1 ERDH work + Temporary storage *3
I-2 Document filing data (Standard + User) *3
I-4 FAX/Internet Fax reception data *2
L-1 System storage data *3
S-1 User data 1 *3
S-10 Pre-install data (e-manual/ Watermark) *3
S-2 Application #1 (Job log data) *3
S-3 Redial information of the address book *3
S-5 Printer spooler *3
S-6 Application work *3
S-9 DSK data save *3
Partition
number
Partition
I-101 FAX/Internet Fax reception data *2
L-101 ICU firmware *3
S-101 ICU firmware fixed data (Pre-install) *3
S-102 ICU firmware fixed data (Mirror) *3
S-103 User data 2 *3
S-105 System data (System setting/ SIM setting data
(Image quality adjustment)/FAX Soft SW)
*3
Partition
number
Partition
I-1 ERDH work + Temporary storage *1
I-2 Document filing data (Standard + User) *1
I-4 FAX/Internet Fax reception data *1
L-1 System storage data *1
S-1 User data 1 *1
S-10 Pre-install data (e-manual/ Watermark) *3
S-2 Application #1 (Job log data) *1
S-5 Printer spooler *1
S-6 Application work *1
S-9 DSK data save *1
Partition
number
Partition
L-101 ICU firmware *3
S-101 ICU firmware fixed data (Pre-install) *3
S-102 ICU firmware fixed data (Mirror) *3
S-105 System data (System setting/ SIM setting data
(Image quality adjustment)/FAX Soft SW)
*3
S-103 User data 2 *1
I-101 FAX/Internet Fax reception data *1
Partition
number
Partition
I-1 ERDH work + Temporary storage *1
I-2 Document filing data (Standard + User) *1
I-4 FAX/Internet Fax reception data *1
L-1 System storage data *3
S-1 User data 1 *1
S-10 Pre-install data (e-manual/ Watermark) *3
S-2 Application #1 (Job log data) *1
S-5 Printer spooler *1
S-6 Application work *1
S-9 DSK data save *1
Partition
number
Partition
I-101 FAX/Internet Fax reception data *1
L-101 ICU firmware *3
S-101 ICU firmware fixed data (Pre-install) *3
S-102 ICU firmware fixed data (Mirror) *3
S-103 User data 2 *1
S-105 System data (System setting/ SIM setting data
(Image quality adjustment)/FAX Soft SW)
*3
Partition
number
Partition
I-1 ERDH work + Temporary storage *3
I-2 Document filing data (Standard + User) *3
I-4 FAX/Internet Fax reception data *3
L-1 System storage data *3
S-1 User data 1 *3
S-10 Pre-install data (e-manual/ Watermark) *3
S-2 Application #1 (Job log data) *2
S-5 Printer spooler *3
S-6 Application work *2
S-9 DSK data save *3
Partition
number
Partition
I-101 FAX/Internet Fax reception data *3
L-101 ICU firmware *3
S-101 ICU firmware fixed data (Pre-install) *3
S-102 ICU firmware fixed data (Mirror) *3
S-103 User data 2 *3
S-105 System data (System setting/ SIM setting data
(Image quality adjustment)/FAX Soft SW)
*3
