Sharp MX-M264N Service Manual

MX-M264U DISASSEMBLY AND ASSEMBLY 10 – 14
Installation * Install so that the cam transmit arm (1) comes under
the roller arm (2).
(2) Reverse sensor
(3) Separation sheet
* Slightly apply grease GP501MR (UKOG-0012QSZZ) around the
axis. One rice grain for each.
(4) Clutch/solenoid
Clutch
Solenoid
Clutch
1
2
2
1
4
3
L
O
C
K
1
3
2
1)
2)
3)
2
1
1
2
2
3
1
2
A
A
A
A
A
A
A

Sharp MX-M264N Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed	26 ppm
Max Print Resolution	600 x 600 dpi
Standard Paper Capacity	1100 sheets
Max Paper Capacity	2100 sheets
Automatic Duplexing	Yes
ADF Capacity	100 sheets
Scan Resolution	600 x 600 dpi
Copy Speed	26 cpm
Copy Resolution	600 x 600 dpi
Connectivity	Ethernet, USB
