MX-M264U ELECTRICAL SECTION 13 – 24
/POGS2a Right paper exit keep
solenoid
Gate select Solenoid ON
(Left paper
exit direction)
– CN1 8 PCU
/POGS2b Right paper exit keep
solenoid
Gate select Solenoid ON
(Right paper
exit direction)
– CN1 9 PCU
/POMA Paper exit motor Motor drive signal Motor ON
(phase
excitation ON)
Motor OFF CN26 4 PCU
POMA Paper exit motor Motor drive signal Motor ON
(phase
excitation ON)
Motor OFF CN26 2 PCU
/POMB Paper exit motor Motor drive signal Motor ON
(phase
excitation ON)
Motor OFF CN26 5 PCU
POMB Paper exit motor Motor drive signal Motor ON
(phase
excitation ON)
Motor OFF CN26 3 PCU
POSD PaperOutputSect sensor Paper transport detection
(Paper exit reverse section)
Paper
provided
– CN21 3 PCU
POUT2A_DET Right paper exit UN
detection
UN installation detection Wight paper
exit UN
connection
detection
Right paper
exit UN not
connected
CN1 10 PCU
POUT2B_DET Second paper exit UN
installation detection
UN installation detection Second paper
exit UN
connection
detection
Second paper
exit UN not
connected
CN3 6 PCU
/PPD1 Manual paper feed entry
sensor
Paper transport detection Paper
provided
– CN21 17 PCU
PSFM_LD1 Power FAN1_LD signal FAN lock detection signal Normal
rotation state
– CN17 5 PCU
PSFM_LD2 Power FAN2_LD signal FAN lock detection signal Normal
rotation state
– CN17 2 PCU
PSFM_V Power FAN_ON signal FAN ON signal – FAN motor
ON
CN17 3 PCU
PSFM_V Power FAN_ON signal FAN ON signal – FAN motor
ON
CN17 6 PCU
/PSPS Process separation pawl
solenoid
Separation pawl drive Solenoid ON Solenoid OFF CN23 8 PCU
PTRC1 Vertical transport clutch 3CS Clutch drive signal Clutch OFF Clutch ON CN14 16 PCU
PTRC2 Vertical transport clutch 2CS Clutch drive signal Clutch OFF Clutch ON CN14 7 PCU
PWM(PGC) For PIC program PIC program writing signal – – CN10 21 PCU
RES_FIN Finisher communication Finisher communication
signal
– – CN7 9 PCU
RES_FINin Finisher installation
detection signal
Finisher installation
detection
FIN
connection
detection
FIN not
connected
CN7 13 PCU
RES_PCU ICU communication ICU-PCU communication
signal
– – CN10 26 PCU
/RRC PS clutch Clutch drive signal Clutch ON – CN19 12 PCU
RTS RIC, PCI (main) send
request
RIC, PCI (main) send
request
Negative Active CN12 7 MFPC
PWB
RTS_PCI PCI (sub) send request PCI (sub) send request Active Negative CN5 5 MFPC
PWB
RTS_PCU ICU communication ICU-PCU communication
signal
– – CN10 24 PCU
RXD RIC,PCI (main) reception
data
RIC,PCI (main) reception
data
– – CN12 2 MFPC
PWB
RxD_FIN Finisher communication Finisher communication
signal
– – CN7 3 PCU
RXD_PCI PCI (sub) reception data PCI (sub) reception data – – CN5 3 MFPC
PWB
RXD_PCU ICU communication ICU-PCU communication
signal
– – CN10 23 PCU
RXD_PIC ICU-PIC communication ICU-PIC communication
signal
– – CN10 13 PCU
SATA_RXN HDD differential data input + HDD differential data input + – – CN22 5 MFPC
PWB
SATA_RXP HDD differential data input – HDD differential data input – – – CN22 6 MFPC
PWB
SATA_TXN HDD differential data output
–
HDD differential data output
–
– – CN22 3 MFPC
PWB
Signal name Name [Type] Function/Operation
Connector level
Connector
No.
Pin
No.
PWB
name
NOTE
"L" "H"
To Next Page
