Electrical
AC Input Ratings
Terminal Description Power Supply Power
L AC line
5.25 A
0 .915 Amps Max @ 230 V, 50/60 Hz
10.25 A
1.25 Amps Max @ 230 V, 50/60 Hz
N AC neutral
W
Ground
ACline and AC neutral terminals are supervised for open and short circuits, provided standby batteries are
functional.
Appendix A: Specifications
SHIELD Fire, Safety & Security Ltd
Aura Fire Alarm Control Panel Installation Manual
Version 1.00 |June 2019 |MAN-1431VS
Page 105
