EVENTS AND STATUS
This section describes events and the status of the panel GUI while operating the Aura Fire Alarm ControlPanel.
The following events are described:
l Fire
l CO
l Trouble
l Supervisory
l Disablement
l Other Events
These event types correspond to the tabs displayed at the top of the Panel GUI. The event tabs will numerically
indicate active events on the panel; the event type with the highest active event priority will automatically be
displayed. Any event type can be accessed by pressing the associated tab.
Fire
In the event of a fire,
l the Fire indicator on the front of the panel flashes red
l the applicable indicator on the Zone LED Board flashes (if connected)
l the panel GUI displays details about the Fire event
l fire warning notification appliances activate as programmed
l panel outputs programmed to operate in the event of a fire, such as the Fire Relay and the Fire Routing
Output 2, will activate
l the panel buzzer activates
With Access Level 2 or higher, the following functions are available:
l Silence Alarms:Press Activate Controls> Silence Alarms to silence notifications. The notifications
can be reactivated by pressing the Re-Sound Alarm button.
