Prog Inputs
Terminals Rating
1, 2, 3
Supervision: None
Open Circuit Voltage:24 VDC
Activation:Short to 0V terminal (< 100 ohms)
Activation current:3.3 mA typical
Fire Routing Input
Supervised input to receive confirmation signal from fire routing equipment. Reprogrammable for any input event
type.
Terminals Rating
(+ ), (- )
Supervision: Class B
Open Circuit Voltage:10V
End-of-Line device:3.3K Ohm resistor
Activation device:680 Ohm resistor
Fire Routing Output 2
Reprogrammable for any output event type.
Terminals Rating
(+ ), (- )
Regulated 24V DC @ 60 mA
Fuse:Self-resetting
Supervision:Reverse-polarity DC
End-of-line device:Diode
Prog Routing Input 1
Programmable for any input event type.
Terminals Rating
(+ ), (- )
Supervision: Class B
Open Circuit Voltage:10V
End-of-Line device:3.3K Ohm resistor
Activation device:680 Ohm resistor
Appendix A: Specifications
SHIELD Fire, Safety & Security Ltd
Aura Fire Alarm Control Panel Installation Manual
Version 1.00 |June 2019 |MAN-1431VS
Page 115
