Main Back Board
NACOutputs
NACOutputs Terminal
NAC 1 (+ ), (- )
NAC 2 (+ ), (- )
NAC 3 (+ ), (- )
NAC 4 (+ ), (- )
NAC 1 and 2 can be configured to provide one Class A circuit (NAC 1&NAC2)or two Class Bcircuits (NAC1
and NAC 2).
NAC 3 and 4 can be configured to provide one Class A circuit (NAC 3&NAC4)or two Class Bcircuits (NAC3
and NAC 4).
Each NACcircuit, whether Class A or Class B, has the following ratings:
AUX Power Output Range
Channels configured to power non-NACdevices are rated special application
20V - 26.4V at 2A max, power-limited. Refer to NACPower Output Modes for
compatible devices.
Quiescent Current Consumption 30 mA
Maximum Current Consumption 50 mA (exclude current draw on outputs)
Current per NACOutput 2.5 A per channel, power-limited
Fuse (Electronic)
Average Current Limit:1 to 2.5A, programmable
Peak Current Limit:3.0 A, fixed per channel
Supervision Reverse-polarity
End-of-Line Device Diode
Short Circuit Threshold 130 Ohms +/- 20%
Maximum Line Impedance 4V loss (load-dependent)
Regulated NAC Outputs
NAC outputs operate in a regulated mode when conforming to specific levels of continuous or pulsed DC. NAC
outputs meet requirements for regulated levels when the output current does not exceed the constraints
described below.
Regulated Non-Pulsing
Output Current
Currents cannot exceed 2.5A from any single NAC output:
Combined currents of all four NAC outputs cannot exceed 5A
