Required Modules for Minimum Operation and Basic
Function
Modules can be added, configured, and replaced without altering field wiring connections. This modularity
allows each Aura Fire Alarm ControlPanel to be customized for a specific operation. Required modules for
minimum operation of an addressable Aura Fire Alarm ControlPanel include:
n System A Panel Module
n System B Panel Module
n Dual Loop Panel Module
Minimum operation describes the Aura Fire Alarm ControlPanel as an operating fire control panel. All modules
are field replaceable.
System A Panel Module (AUL-9069)
System A Panel Module provides essential functions on the Aura Fire Alarm ControlPanel. These functions
include:
Functions Description
NAC 1 and NAC 2 Class A or two Class B. Default Class B.
NAC 3 and NAC 4 Class A or two Class B. Default Class B.
PSU monitor Battery disconnected, power failure, battery low, PSU ground trouble, charger trouble.
Power fail input A connection of <2K to 0V will indicate a power fail
Ground trouble
A connection of 30K or less between a back board terminal (except volt-free terminals)
and the ground will be indicated by a trouble.
Overview
SHIELD Fire, Safety & Security Ltd
Aura Fire Alarm Control Panel Installation Manual
Version 1.00 |June 2019 |MAN-1431VS
Page 53
