Terminals
The default designation is as shown below, however all 5 relays are user-configurable.
Field Terminals Default Operation Default Setting
NO, C, and NC TROUBLE RELAY Trouble
NO, C, and NC FIRE RELAY Fire
NO, C, and NC SUPERV RELAY Supervisory
NO, C, and NC PROG 1 RELAY Transparent
NO, C, and NC PROG 2 RELAY Transparent
SHIELD Fire, Safety & Security Ltd
Aura Fire Alarm Control Panel Installation Manual
Version 1.00 |June 2019 |MAN-1431VS
