Shield Aura - Prog Routing Output; Prog Routing Input 2; Trouble Routing Output; Trouble Routing Input

Prog Routing Output
Terminals Rating
(+ ), (- )
24V max.
Impedance between (+) and (-) terminals measures 3.3K ohms when inactive.
Impedance between (+) and (-) terminals measures 680 ohms when active.
Prog Routing Input 2
Programmable for any input event type.
Terminals Rating
(+ ), (- )
Supervision: Class B
Open Circuit Voltage:10V
End-of-Line device:3.3K Ohm resistor
Activation device:680 Ohm resistor
Trouble Routing Output
Reprogrammable for any output event type.
Terminals Rating
(+ ), (- )
Regulated 24V DC @ 60 mA
Fuse:Self-resetting
Supervision: Load >5 mA
End-of-line device:3.3K ohms if load < 5 mA
Trouble Routing Input
Reprogrammable for any input event type.
Terminals Rating
(+ ), (- )
Supervision: Class B
Open Circuit Voltage:10V
End-of-Line device:3.3K Ohm resistor
Activation device:680 Ohm resistor
SHIELD Fire, Safety & Security Ltd
Aura Fire Alarm Control Panel Installation Manual
Version 1.00 |June 2019 |MAN-1431VS
Page 116
Appendix A: Specifications
