Shield Aura - LED Status Indicators; Panel Leds; Fire in Zone Indicators

LEDStatus Indicators
Panel LEDs
For complete information about each event type, refer to Events and Status.
Fire In Zone Indicators
Fire In Zone indicators are an optional feature provided on the fascia of the Aura Fire Alarm ControlPanel in
single, double, or triple bank configurations. The following figure illustrates a single bank of 48 Fire In Zone
indicators:
