Panel Module Slots and Terminals
Panel module slots and field terminals of the Aura Fire Alarm ControlPanel contain corresponding lettering to
identify position on the Extension Board. Slots G, H, J, and K correspond to terminals G, H, J, and K of the
Extension Board.
Location Field Wiring Terminals Function
Slot G 1-4 , 5-8, and 9-16 Loop 9 and Loop 10
Slot H 1-4 , 5-8, and 9-16 Loop 11 and Loop 12
Slot J 1-4 , 5-8, and 9-16 Loop 13 and Loop 14
Slot K 1-4 , 5-8, and 9-16 Loop 15 and Loop 16
RS-485 I/O N/A Not currently used. For future use.
0V, PF, E N/A Not currently used. For future use.
24V and 0V Power
Terminals
N/A
Used to power the board through a connection to the Main Back
Board.
Extension Board (AUL-9086)
