Item Description
Dual Loop Panel Module
The Dual Loop Panel Module provides two addressable loop functions for the fire alarm
control panel. All models of the Aura Fire Alarm ControlPanel contain at least one Dual Loop
Panel Module.
Ground Cable(s)
Ground cabling is green and yellow, insulated wire containing connecting lugs. Ground
cabling provides common electrical grounds of the cabinet to the lid, fascia, and backplate.
14 Conductor PSU Cable
The 14 Conductor PSU Signal Cable connects from the power supply to the Main Back
Board.
34 Conductor Cable The 34 Conductor Cable connects the Main Back Board to the LCD Main Processor Board.
40 Conductor Cable The 40 Conductor Cable connects the Main Back Board to the LCD Main Processor Board.
10 Conductor Zone LED
Cable
(optional)
The 10 Conductor Zone LED Cable connects from the Zone LED Module to the LCD Main
Processor Board.
10 Conductor Zone LED to
LED Cable (optional)
The 10 Conductor Zone LED to LED Cable connects from one Zone LEDModule to the next
Zone LEDModule. This cable is required when two or more Zone LEDModules are installed
on the fascia.
10 Conductor Printer Cable
(optional)
The 10 Conductor Printer Cable connects the printer assembly to the LCD Main Processor
Board.
4. The following items are not included with the Aura Fire Alarm ControlPanel, but may be required for the
installation:
l Two 12 VDC VRLA (Valve-Regulated Lead Acid) Standby Batteries - Required
l Mounting Hardware - Mounting hardware that secures the panel to the wall is not provided. Screws
should be either a #10 or #12.
l A Ground Strap is required for handling circuit boards.
