2 Starting GC/MS
6 GCMS-QP2010 Series Operation Guide
2.4 System Configuration
Check and set the modules used for analysis using the procedures described below.
2.4.1 Setting the Modules Used for Analysis
1
Click the [System Configuration] icon on the [Real Time] assistant bar.
The [System Configuration] window opens.
2
Check that the components shown in the [Modules Used for Analysis] area correspond
to the actual modules in the GC/MS system that are to be used for the analysis.
If the modules to be used for current analysis do not correspond to the modules shown in
this window, set as shown in the following example:
1 Select [AOC-20i+s] in the [Available Modules] area if for example, AOC-20i with AOC-20s are to be
used for analysis.
2 Click to register the module in [Modules Used for Analysis].
1 2
