8009389/YN39/V3-0/2015-08| SICK OPERATING INSTRUCTIONS|GM35
Subject to change without notice
TROUBLESHOOTING AND CLEARING MALFUNCTIONS
Mirror adj. End
Automatic beam tracking at end stop,
further tracking not possible.
▸ Check alignment;
see page 111.
▸ Contact Service.
Mirror com.
No communication with automatic
beam tracking; measurement
continues to run.
▸ Contact Service.
Sensor
communication
No connection between EvU and
GM35.
▸ Check CAN connection, repair if necessary.
VISOR com.
CO
2
/H
2
O module not connected to
visor unit.
▸ Check cable connection is secure with correct
seat; repair if necessary.
▸ If the error cannot be cleared: Contact Service.
VISOR fault
Visor unit data invalid or signals
distorted.
▸ Check alignment;
see page 111.
▸ If no display seen in visor during alignment or if
message remains despite correct alignment,
contact Service.
VISOR init. Visor default setting invalid.
▸ Contact Service.
VISOR No signal
● Visor signals too low.
● Dust content too high.
● IR source defective.
Measurement continues to run.
▸ Check contamination; clean optical interfaces (
see
page 104
f).
▸ Check optical alignment,
see page 111.
▸ Exchange IR source or contact Service.
Zero com.
CO
2
/H
2
O module not connected to
motor of zero point reflector.
▸ Check cable connection is secure with correct
seat; repair if necessary.
▸ If the error cannot be cleared: Contact Service.
Error message Component/possible causes Clearance
