8009389/YN39/V3-0/2015-08| SICK OPERATING INSTRUCTIONS|GM35
Subject to change without notice
CONNECTING THE SYSTEM CONTROL UNIT - SCU
This menu shows:
• Measuring operation of the analyzer
• Current measured values and reference conditions
6.1.8 Menu Parameter
Menu GM35/Parameter/Device Parameter
Fig. 29: Menu: Device Parameter
This menu serves to make the following settings:
• Available measuring components (CO, CO
2
, H
2
O)
• Connected device components (CAN connection: Probe, type or cross-duct)
• Network connection (SCU/GM35 address, baud rate)
• Average time
• Control cycle interval (CCY Rep. Time)
• Active measuring path (Measuring distance)
• Regression function of the measuring components (zero point, span point)
