CONNECTING THE SYSTEM CONTROL UNIT - SCU
6 Connecting the System Control Unit - SCU
As an option, the GM35 can be operated and configured via an SCU. The SCU is a control
unit for comfortable, powerful analyzer control. The following actions can be performed on
the GM35 via the SCU:
• Control, parameter setting and display.
• Processing and saving measured values.
• Remote diagnosis.
The SCU is connected to the GM35 evaluation unit via a system bus and is operated via a
touchscreen or a PC with SOPAS software installed.
6.1 SCU connection to the GM35
6.1.1 Electrical connection of the SCU to the GM35
6.1.2 Configuring and operating using SOPAS
Operator menus and measured value displays are also available on an external PC via
Ethernet for user comfort (with the engineering tool SOPAS ET).
The SICK Open Portal for Applications and Systems (SOPAS) is a software for
communication with analyzers and sensors.
Access to the GM35 is possible via:
• a direct serial connection (RS232) to the evaluation unit.
• an Ethernet connection via an SCU operating unit to the evaluation unit.
Further information on the SCU → “SCU” Operating Instructions.
CAUTION: Higher malfunction susceptibility when used in unspecified
ambient conditions
▸ Take all measures possible to protect equipment/module against
dampness, liquids or contamination.
▸ Protect the equipment/module against mechanical or thermal stress.
The electrical connection of the SCU to the GM35 is described in “Connection
to the SCU (System Control Unit):”, page 45
.
