8009389/YN39/V3-0/2015-08| SICKOPERATING INSTRUCTIONS|GM35
Subject to change without notice
PROJECT PLANNING INFORMATION
3.7 Electrical protection
Evaluation units of GM35, Power Supply 24 V; SCU I/O
• Insulation: Protection class 1 in accordance with EN 61140
• Insulation coordination: Overvoltage category II in accordance with EN61010-1
• Contamination: Degree of contamination II in accordance with DIN EN 61010-1
3.8 Specifications on electric isolation of the EvU
WARNING: Endangerment of electrical safety through heat damage to lines
When planning the lines, take into account that the connection unit can reach
a temperature >60°C due to self-heating at maximum ambient temperature.
▸ Only use lines specified for temperatures >80°C.
Connections SCU I/O
Relay contact <-> PE 860 V AC
Relay contact <-> relay contact 860 V AC
Relay contact <-> actuation 1376 V AC
Table 4: Characteristic data for electric isolation
