SICK GM35 User Manual

145
8009389/YN39/V3-0/2015-08| SICK OPERATING INSTRUCTIONS|GM35
Subject to change without notice
TECHNICAL DATA, CONSUMABLES AND SPARE PARTS
11.3.5 Spare parts for purge air unit
11.3.6 Spare parts, miscellaneous
11.3.7 Fixing accessories
Fixing accessories, measuring probe - flange
Fixing accessories, SR-unit - measuring probe
2 017 329 Hinge pin
6 010 378 Lithium battery 3.00 V CR2032
Part No. Name
Part No. Name
5 306 090 Air filter, complete, Europiclon
5 306 091 Filter element, Micro-Top-Element
4 708 971 Distributor, 2xDN40
4 022 766 Purge air hose, DN40, length 5 m
5 700 520 Hose clamp, DN40-60x12
Part No. Name
2 023 688 Mains cable for SR-unit or probe, 4 m, 3 x 1.5
2
2 023 687 Connection cable, evaluation unit – sensor, 4 m
2 023 704 CAN-bus cable, SR-unit - probe, 0.6 m, 3 x 2 x0.75
2
Part No. Name
5 700 457 Screw, 6 Kt M16x60-A2
5 700 482 Washer, A17-A2
5 700 471 Nut, 6 Kt M16 A2
5 700 480 Lock washer, A16
Part No. Name
5 700 484 Cup springs A25
5 700 472 Nut, SSI M12
5 700 494 Spherical washer
2 017 329 Hinge pin for GM35 flange fixture
4 023 743 Sealing tape
