3.4 Integrated illumination
3
4
1
1
1
1
1
1
2
2
1
1
Figure 3: Illumination unit (integrated illumination), example product type V2D61xx-xMxxxx
1
8 integrated illumination LEDs (color: 4 visible amber light, 4 visible blue light)
2
2 LED alignment aids, can be deactivated (color: visible red light)
3
Feedback LED (color: visible green light, visible red light; green for example for Good
Read, red for example for No Read)
4
Time-of-flight sensor for measuring the working distance in configuration mode (color:
invisible infrared light)
