11.5 Interfaces
Lector610 Lector611
Ethernet Protocol:
•
TCP/IP
•
EtherNet/IP
•
Modbus® TCP
Function: host (data output of the read result)
Function: AUX (service)
1)
Data transmission rate: 10/100Mbit/s
Services: DHCP, NTP, HTTP, mDNS, DNS-SD, DNS, HTTPS.
MAC address (device-specific), see type label
Serial RS-232 Function: host (data output of the read result)
Data transmission rate: 0.3kBd ... 115.2kBd
CAN Protocol:
•
A connection in a CANopen-based environment is possible. For
additional support, please contact SICK customer service.
•
SICK CAN sensor network CSN (master/slave, multi‐
plexer/server)
Function: host (data output of the read result)
Data transmission rate: 20kBit/s ... 1MBit/s
Bus length: maximum 30m
PROFINET (line topology) Function: host (data output of read result), PROFINET Single Port
Data transmission rate: 10/100Mbit/s
Function blocks for various PLC manufacturers are available online
on the product page.
Digital inputs Type: 2 x physical, switching (“Sensor 1”, “Sensor 2”)
V
in

2)
= maximum 27.6V, I
in

3)
= max. 5mA
Opto-decoupled, not reverse polarity protected regarding supply
voltage
Debounce time: adjustable
4)
Encoder frequency: max. 300Hz
Digital outputs Type: 3 x physical, switching (“Result 1” ... “Result 3”)
V
out

5)
= V
S

6)
– 1.5V, I
out

7)
≤50mA (typical)
Short-circuit protected, not electrically isolated from the supply
voltage V
s
Reading pulse Digital inputs, free, serial interface, Ethernet, CAN, auto pulse or
presentation mode
Optical indicators 6 status LEDs on the side of the product
2 LED alignment aids on the front side of the product
1 feedback LED (green and red) as a light spot on the code
Operating elements 1 function button (select function, start and end)
Operator interfaces Web server
Configuration software
(parameterization)
SOPAS ET configuration software, web server, CoLa commands
(telegrams), fieldbus controller (PLC) with additional support by
SICK function blocks, function button
Data storage and retrieval Image and data storage via internal memory and external FTP
Maximum encoder fre‐
quency
300Hz
1)
Service: Image display, configuration and diagnostics.
2)
Input voltage.
3)
Input current.
4)
For example using the SOPAS ET configuration software.
TECHNICAL DATA 11
8024830/1MBT/2024-05-22 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector61x
55
Subject to change without notice
