SICK Lector61x User Manual

Device 3CDB650-204
V
S
V
S
2
1
5
Shield
1 U
IN
2 GND
U
IN
*
GND
S1
F
Shield
GND
.
.
.
.
.
.
ON
OFF
S1 : POWER
V
s
U
IN
*
POWER
GND
3
1
7
2
6
5
4
8
13
14
17
15
9
10
12
16
11
V
S
- U
IN
-
F
S 1
- U
IN
*
4
1
Cable 2
Figure 31: Connecting supply voltage for the device in CDB650-204 connection module.
1
Supply voltage V
S
2
Connecting cable permanently connected with the device (male connector, M12, 17-pin,
A-coded)
3
Device
4
Connection module: female connector, M12, 17-pin, A-coded
Function of switch S1
Table 21: Switch S1: Power
Switch setting Function
ON Supply voltage U
IN
connected to CDB650-204 and device via fuse and
switch S1 as a supply voltage U
IN
*
Supply voltage U
IN
* can be additionally tapped at terminals 11 and 14.
OFF CDB650-204 and device disconnected from supply voltage
Recommended setting for all connection work
13.3.4 Wiring serial host interface RS-232 of the device in CDB650-204
Device = Lector61x = V2D61xx- xxxxxEx
13 ANNEX
64
O P E R A T I N G I N S T R U C T I O N S | Lector61x 8024830/1MBT/2024-05-22 | SICK
Subject to change without notice
