11 Technical data
NOTE
The relevant online product page for your product, including technical data, dimensional
drawing, and connection diagrams, can be downloaded, saved, and printed from the
Internet.
The product page can be accessed via the SICK ProductID: pid.sick.com/{P/N}/{S/N}
{P/N} corresponds to the part number of the product, see type label.
{S/N} corresponds to the serial number of the product, see type label (if indicated).
Please note: This documentation may contain further technical data.
11.1 Features
Type Lector610 Lector611
Focus V2D61xx-xxMxxxx: Manually adjustable focus with focus adjust‐
ment tool
V2D61xx-xxLxxxx: Liquid lens, automatic focus adjustment
Sensor resolution 0.3Mpx (640px x 480px) 1.2Mpx
Integrated illumination
unit
8 LEDs:
•
4 LEDs with visible amber light (λ = 617nm ±50nm)
•
4 LEDs with visible blue light (λ = 470nm ±15nm)
Feedback LED (spot in field
of view)
1 LED:
•
Visible green light (λ = 525nm ±15nm)
•
Visible red light (λ = 635nm ± 15nm)
LED alignment aid (2
points in the field of view)
2 LEDs, can be deactivated:
Visible red light (λ = 630nm ±15nm)
LED risk group Integrated illumination unit:
Risk group 1 (low risk) according to IEC 62471-1: 2006-07/EN
62471-1: 2008-09 including EU Directive 2006/25/EC (DIN EN
62471:2009-03 is identical to EN 62471:2008-09).
Radiance
•
L
B

1)
: <10 x 10
3
W/(m
2
sr) within 100seconds; at distance
≥200mm
•
L
R

2)
: < 2.2 x 10
6
W/(m
2
sr) within 10seconds; at dis‐
tance ≥ 200mm
Distance-dependent hazard value
•
Risk group 0 (no risk) based on L
B
1)
: <100W/(m
2
sr) within
10,000seconds; at a distance of >2.0m.
Feedback LED, LED alignment aid and status LEDs:
Risk group 0 (no risk) according to IEC 62471-1: 2006-07/EN
62471-1: 2008-09 including EU Directive 2006/25/EC (DIN EN
62471:2009-03 is identical to EN 62471:2008-09).
MTBF of LEDs Integrated illumination unit, feedback LED and LED alignment
aid:
75,000h, at 25°C ambient operating temperature
Time-of-flight sensor 1 laser (distance measurement in configuration mode):
Invisible infrared light (wavelength 940nm, maximum output
power ≤17.5mW, pulse length ≤3.7ns)
TECHNICAL DATA 11
8024830/1MBT/2024-05-22 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector61x
51
Subject to change without notice
