6.5 Connecting
6.5.1 Using CDB and CDM connection modules
Connection on the device Connection modules Connection cable
Connecting cable with male connec‐
tor, M12, 17-pin, A-coded
CDB650-204 Connecting cable
CDM420-0006
1)
Adapter cable
2)
1)
CDM420-0007: for connecting 2 devices.
2)
Adapter cable (female connector, M12, 17-pin, A-coded / male connector, D-Sub-HD, 15-pin).
Connecting device with connection module
Connection modules Reference
CDB650-204 see "Connection of the device to CDB650-204", page 61
CDM420-0006 see "Connection of the device to CDM420-0006", page 70
NOTE
The operating instructions of the connection modules contains detailed information
on mounting and electrical installation. The operating instructions are available as a
download on the product page of the connection module.
Connection module product page
•
www.sick.com/CDB
•
www.sick.com/CDM
6.5.2 Connecting the supply voltage
The voltage source meets the requirements of ES1 and PS2 (EN62368-1) or SELV and
LPS (EN60950-1).
Table 5: Required supply voltage V
S
and power output
Supply voltage V
S
Power source: required power output
1)
DC 12V ... 24V ±15% Maximum 16W
1)
Valid for device with 3 loaded digital outputs (each 50mA).
Table 6: Typical current consumption depending on supply voltage
Designation Supply voltage (V
S
) in [DC V]
10.2
(12V -15%)
12 24 27.6
(24V +15%)
Current consumption, digi‐
tal outputs unloaded
I
B RMS
[A] 0.290 0.244 0.128 0.110
Power loss, digital outputs
unloaded
P
RMS
[W] 2.96 2.93 3.07 3.04
Maximum current con‐
sumption, digital outputs
unloaded
I
B Peak
1)
[A] 1.06 0.848 0.387 0.331
Typical, all 3 digital outputs
loaded (0.05A per output)
I
B RMS 3Out
[A]
0.44 0.394 0.278 0.26
Power loss, all 3 digital out‐
puts loaded (0.05A per
output)
P
Peak 3Out
[W]
14.6 15.09 15.61 15.831
1)
Valid for the power supply unit rating, supply cable and fuse protection at the start of the cable.
6 ELECTRICAL INSTALLATION
36
O P E R A T I N G I N S T R U C T I O N S | Lector61x 8024830/1MBT/2024-05-22 | SICK
Subject to change without notice
