3.6 Working distance and field of view size
Working distance and field of view size
2
3
2
3
1
1
Figure 5: Working distance and field of view size
1
Working distance in mm
2
Perceived field of view area: horizontal (mm)
3
Perceived field of view area: vertical (mm)
The field of view size is determined by the focus position, the focal length of the lens,
and the working distance. The necessary working distance can be determined from the
field of view diagram.
Reference edge for the working distance
The working distance is measured from the edge of the blue part of the housing.
1
1
Reference edge for the working distance from the product to the object
Further topics
•
Field of view
PRODUCT DESCRIPTION 3
8024830/1MBT/2024-05-22 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector61x
17
Subject to change without notice
