Table 2: LEDs in PROFINET operation (single port)
Ready LED Product status Remarks
Green com‐
ponents
Red compo‐
nents
O o
The product is ready for
operation.
O Ö
Flashes
every 7sec‐
onds.
Network detection in the
product is active.
The duration of network detection
can be configured in SOPAS ET
(default: 3minutes).
O Ö
Flashes
every
0.5seconds.
PROFINET is activated in
the product. The product is
not connected to the PRO‐
FINET IO controller (PLC) or
the product is not config‐
ured.
To not use PROFINET, deactivate
PROFINET.
In the default configuration of the
product, automatic PROFINET net‐
work detection is activated. This
detects during startup whether the
product is in a PROFINET environ‐
ment and activates PROFINET auto‐
matically.
To prevent this, deactivate PROFINET
network detection or set the product
name or IP address different from
the default.
To apply the changed settings, per‐
manently save the changes and
restart the product.
Ö
Ö
The flashing function is acti‐
vated via the configuration
software.
The red and green components of
the LED flash alternately.
Prerequisite: PROFINET is activated
in the product.
O = lights up; Ö = flashes; o = does not light up
Product functions
Function Description
Test Checking stability of code reading:
The product records a series of images and uses the current reading
performance settings to decode them. To assess the code reading
stability, check the feedback LED.
Aiming Switching LED alignment aid on and off:
The LEDs can be switched off so that the LED alignment aids do not
influence the code reading. To switch the LED alignment aid back on
again, run the Aiming function again.
Focus Adjust focus position with the focus adjustment tool.
Tuning The product automatically adjusts to suit the lighting conditions and
the quality of the code presented. Product type V2D61xx-xLxxxx also
automatically adjusts the focus position. The product permanently
stores the acquired values.
The Tuning function is not supported for pharmacodes.
Function button and product functions in configuration mode
The function button is used to call up product functions manually without using a
computer. On the third display level, the LEDs indicate the selectable product functions
and the execution of a product function.
3 PRODUCT DESCRIPTION
