1
Ethernet (host port)
2
Serial host interface
3
Switch
4
CAN controller
5
CAN device
6
Device number
7
CAN etc.
8
Branch line
9
Adapter cable with female connector, M12, 17-pin, A-coded and male connector, D-Sub-HD, 15-pin
ß
Device number (GN)
à
Maximum 32 users
á
Example of alternative connection module:
CDB650-204
NOTE
Activate the CAN data interface in the device using a configuration software, e.g.,
SOPASET.
Configure further settings in the device according to the function of the device in the
system configuration.
13.4.6 Wiring digital inputs of the device in the CDM420-0006
Device = Lector61x = V2D61xx-xxxxxEx
Device 4
CDM420-0006
PNP sensor 8
V
S
V
S
V
S
GND
SensGND
52.3 K
3 K
Sensor E
V
in
D
9
2
1
C
15
1
5
Out
+24V*
GND
S6
ON
OFF
S6 : SGND-GND
Shield
GND
.
.
.
A
Sensor B
37
SGND
6
Shield
39
+24 V*
GND
SensGND
3
1
7
2
6
5
4
8
13
14
17
15
9
10
12
16
11
Trigger sensor 1
9
E.g. photo-electric
switch 7
3
6 5
110
15
6
11
5
Cable 2
Figure 42: Trigger sensor supplied with power by connection module CDM420-0006
1
Trigger sensor
2
Adapter cable with male connector, D-Sub-HD, 15-pin and female connector, M12, 17-pin, A-coded
3
Input voltage V
in
4
Device
5
Connecting cable permanently connected with the device (male connector, M12, 17-pin, A-coded)
6
Connection module: female connector, D-Sub-HD, 15-pin
7
E.g. photoelectric sensor
8
PNP sensor
9
Supply voltage V
S
13 ANNEX
76
O P E R A T I N G I N S T R U C T I O N S | Lector61x 8024830/1MBT/2024-05-22 | SICK
Subject to change without notice
