Table 31: Assignment of placeholders to the digital outputs
Device CDM420-0006
Output A Pin B Pin C Signal D Terminal E
Result 1 13 12 Result 1 14
Result 2 14 13 Result 2 15
Characteristic data of the digital outputs
Table 32: Characteristic data of the and digital outputs
Type Switching
Switching behavior PNP switching to supply voltage V
S
Default settings in the device: no function, logic: not inverted (active
high)
Properties
•
Short-circuit protected and temperature protected
•
Not electrically isolated from the supply voltage V
S
Electrical values 0V ≤ V
out
1)
≤ V
S
(V
S
−1.5V) ≤V
out
≤V
S
at I
out
2)
≤50mA
1)
Output voltage.
2)
Output current.
NOTE
Allocate the functions for the digital outputs in the device using a configuration soft‐
ware, e.g., SOPASET.
13.5 Licenses
SICK uses open source software which is published by the rights holders under a
free license. Among others, the following license types are used: GNU General Public
License (GPL version2, GPL version3), GNU Lesser General Public License (LGPL), MIT
license, zlib license and licenses derived from the BSD license.
This program is provided for general use without warranty of any kind. This warranty
disclaimer also extends to the implicit assurance of marketability or suitability of the
program for a particular purpose.
More details can be found in the GNU General Public License.
For license texts see www.sick.com/licensetexts.
Printed copies of the license texts are also available on request.
ANNEX 13
8024830/1MBT/2024-05-22 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector61x
79
