NOTE
Allocate the functions for the digital inputs in the device using a configuration software,
e.g., SOPASET.
13.4.7 Wiring digital outputs of the device in the CDM420-0006
Device = Lector61x = V2D61xx-xxxxxEx
Device 1
CDM420-0006
Load (e.g. PLC) 4
C
5
.
.
.
E
Result D
13
GND
5
Shield
+24 V* (V
S
)
V
S
GND
V
out
Result A
GND
B
1
2 1
For inductive load: 6
5
2
3
3
1
7
2
6
5
4
8
13
14
17
15
9
10
12
16
11
8 7
110
15
6
11
5
Figure 44: Wire the digital output in the CDM420-0006 connection module.
1
Device
2
Supply voltage V
S
3
Adapter cable with female connector, M12, 17-pin, A-coded and male connector, D-Sub-HD, 15-pin
4
Load (e.g. PLC)
5
Output voltage V
out
6
With inductive load: see note
7
Connection module: female connector, D-Sub-HD, 15-pin
8
Connecting cable permanently connected with the device (male connector, M12, 17-pin, A-coded)
NOTE
Digital outputs are omitted due to the 15-pin adapter cable.
Not available in CDM420-0006:
•
Result 3
Inductive load
NOTE
Provide an arc-suppression switch at the digital output if inductive load is present.
►
Attach a freewheeling diode directly to the load for this purpose.
13 ANNEX
78
O P E R A T I N G I N S T R U C T I O N S | Lector61x 8024830/1MBT/2024-05-22 | SICK
Subject to change without notice
