SICK Lector61x - 13.3.5 Wiring the CAN interface of the device in the CDB650-204

3
1
7
2
6
5
4
8
13
14
17
15
9
10
12
16
11
Device 1 Host
1
.
.
.
TxD
RxD
RxD
TxD
GND
GND
GND
6
12
43
T‒/TxD
44
R‒/RxD
42
GND
6
Shield
RS-232 RS-232
422
485
S6 : RS
ON
OFF
S7: Term 485
S6
422485
3
Cable 2
CDB650-204
Figure 32: Wiring data interface RS-232 of the device in connection module CDB650-204.
1
Device
2
Connecting cable permanently connected with the device (male connector, M12, 17-pin, A-coded)
3
Connection module: female connector, M12, 17-pin, A-coded
NOTE
Activate the RS-232 data interface in the device using a configuration software, e.g.,
SOPASET.
13.3.5 Wiring the CAN interface of the device in the CDB650-204
Device = Lector61x = V2D61xx-xxxxxEx
Not considered: connection and looping through of the supply voltage, connection of a
trigger sensor for read cycle generation (e.g. at the CAN controller)
ANNEX 13
