SICK Lector61x User Manual

Type Lector610 Lector611
Laser class Time-of-flight sensor:
Class 1 Laser Product according to EN 60825-1:2014+A11:2021;
IEC 60825-1:2014. Complies with 21 CFR 1040.10 except for
conformance with IEC 60825-1 Ed. 3.0 as described in “Laser
Notice 56” dated May 8, 2019.
Scanning frequency 1.2Mpx: maximum 40Hz at full resolution
Code resolution f = 12mm:
•
≥0.04mm (1D code)
•
≥0.08mm (2D code)
f = 6mm:
•
≥0.1mm (1D code)
•
≥0.2mm (2D code)
f = 12mm:
•
≥0.02mm (1D code)
•
≥0.04mm (2D code)
f = 6mm:
•
≥0.05mm (1D code)
•
≥0.1mm (2D code)
The code resolution depends on the lens and the working dis‐
tance.
The specifications are valid for 1D codes and 2D codes with good
print quality.
Working distance 50mm…300mm
3)
Lens Focal length
•
V2D61xx-xxxxBxx: 6mm
•
V2D61xx-xxxxCxx: 12mm
1)
L
B
= Hazard from blue light.
2)
L
R
= Hazard to the retina of the eye due to heating.
3)
With internal illumination, can be extended to greater distances when using external lighting.
Valid for Data Matrix, PDF417, and 1D codes with good print quality.
For details: Field of view.
11.2 Mechanics/electronics
Lector610 Lector611
Electrical connection 1 cable (length: 0.35m) with male connector, M12, 17-pin, A-coded
•
Maximum length: 30m
•
Maximum length when used as a serial interface: 15m
1 cable (length: 0.25m) with female connector, M12, 4-pin, D-coded
Supply voltage V
S
DC 12V ... 24V, ±15%
Voltage source in accordance with ES1 and PS2 (EN62368-1) and
according to SELV and LPS (EN60950-1).
Power consumption Operation: 3.5W typical
1)
Maximum 16W (peak) with typical loading of the 3 digital outputs with
50mA each and 27.6V DC supply voltage
Current consumption Max. 1.5A (peak) at 10.2V DC
Housing material Die cast aluminum, plastic
Housing color Light blue (RAL 5012), black
Viewing window mate‐
rial
Plastic (PMMA), 2mm thick
Enclosure rating V2D61xx-xxxxxx4: IP 54 (EN 60529, EN60529/A2)
2)
V2D61xx-xxxxxx5: IP 65 (EN 60529, EN60529/A2)
2)
Protection class III
Electrical safety EN 62368-1
Weight 165g, including connecting cables
11 TECHNICAL DATA
52
O P E R A T I N G I N S T R U C T I O N S | Lector61x 8024830/1MBT/2024-05-22 | SICK
Subject to change without notice
