Chapter 9
MSC800
8011540/14B8/2019-06-06 Operating instructions | SICK 91
Subject to change without notice
Type MSC800-1100
MSC800-2100
MSC800-2300 MSC800-3400
MSC800-3600
See chapter 5.4.3 Cable entries on page 58
See chapter 5.4.5 Circuit breakers and fuses on page 60
Fan MSC800-2100/-2300: 1 fan, temperature-controlled
MSC800-3400/-3600: 2 fans, temperature-controlled
Switching on/off temperature 37.5 °C
Supply voltage AC 100 ... 264 V / 50 ... 60 Hz
Power supply unit module output voltage
Power supply unit module current output 10 A 30 A MSC800-3400: 40 A
Logic unit power consumption Typ. 10 W
Battery for real time clock Button cell, type CR 2032; 3.0 V
2)
Acc. to EN 61439-2: 2011-10
Protection class I, as per EN 61140 (2002-03); A1 (2006-08)
Enclosure rating
(as per EN 60529 (1991-10);
A1 (2002-02))
MSC800-1100: IP 65
MSC800-2100: IP 54
IP 54 IP 54
As per EN 61000-6-2 (2001-10), EN 61000-6-4 (2001-10)
Thorough vibration/shock check
As per IEC 68-2-6/ IEC 68-2-27
Dimensions MSC800-1100:
See dimensional drawing on
page 92
MSC800-2100:
See dimensional drawing on
page 93
See dimensional drawing
on page 94
See dimensional drawing
on page 95
Weight Incl. power supply unit
module:
MSC800-1100: approx. 10 kg
MSC800-2100: approx.
15.6 kg
Incl. power supply unit
modules:
Approx. 16.5 kg
Incl. power supply unit
modules:
MSC800-3400:
approx. 17.2 kg
MSC800-3600:
approx. 19.3 kg
Mounting MSC800-1100:
2 perforated plates each with
3 holes 8.7 mm
MSC800-2100:
2 perforated plates with
2 perforated plates with
5 holes each 8.7 mm
2 perforated plates with
5 holes each 8.7 mm
Ambient operating temperature/storage
0 ... +40 °C/–20 ... +70 °C
Max. rel. air humidity ≤ 95%, non-condensing
Color Light gray (RAL 7035)
1) With labeling MSC800-0000.
2) Outside of the cabinet, no materials using silicon.
Tab. 52 MSC800 technical specifications
