11.1.2 Internal sensors
GPS accuracy
GNSS GPS
Horizontal position
accuracy*
2.5 m
* CEP, 50%, 24 hours static, -130 dBm, > 6 SVs
Tab. 9: GPS accuracy
Motion sensor accuracy
Full scale area ± 2 g / 4 g / ± 8 g
Resolution Up to 0.244 mg
Update rate 1.56 Hz to 400 Hz
Tab. 10: Motion sensor accuracy
Position sensor accuracy
Full scale area ± 12,000 mGa
Resolution Up to 1 mag
Update rate 1.56 Hz to 400 Hz
Tab. 11: Position sensor accuracy
Thermometer accuracy
Resolution ± 0.5 °C
Accuracy ± 0.5 °C from 20 °C to 100 °C
Tab. 12: Thermometer accuracy
