8.2.9 Serial interfaces
▸
Open the RS232 or RS4xx connection parameters via the gear icon.
▸
Activate inputs via the Enabled checkbox and set the baud rate.
NOTE Only one of the two serial interfaces can be activated at a time.
Rs232Data
WebSocket server URL
ws://192.168.0.100:31768/ws/tdce/rs232/data
MQTT subscription directory
tdce/rs232/out
MQTT publish directory
tdce/rs232/in
Results
dGVzdA==
Rs4xxData
WebSocket server URL
ws://192.168.0.100:31768/ws/tdce/rs4xx/data
MQTT subscription directory
tdce/rs4xx/out
MQTT publish directory
tdce/rs4xx/in
Results
dGVzdA==
API
Rs232 / Rs4xx
