3 System description
3.1 Scope of delivery
NOTE!
▸
After delivery, inspect the system for transport damage and report any such damage
immediately.
▸
Check that the delivery includes all components listed on the delivery note.
Fig. 1: System components
Legend
1 TDC-E
2 WLAN antenna
3 LTE antenna
4 GPS antenna
5 Voltage supply cable
6 Quickstart
Quantity Part no. Description
n 6070344
or
6079357
TDC-E210xx
n 6074432 WLAN antenna
n 6077804 LTE antenna
n 6067023 GPS antenna, 3 m
n 6068473 Voltage supply cable, 0.9 m
n 8022507 Quickstart guide including download link for the operating
instructions, system documentation, and interface descriptions
