SYSTEM DESCRIPTION 3
8027311 / V1-0/2022-04|SICK
Subject to change without notice
OPERATING INSTRUCTIONS|TDC-E (Telematic Data Collector)
3.3 Data processing
Fig. 4: Data processing
• The merged data is filtered and simple evaluations, such as diagnostics of limit value
overshoots, can be done.
• Pre-processing can reduce response time and transmission costs.
• Data processing is performed via applications that can be quickly implemented using
the TDC-E microservice architecture.
• Node-Red, for example, is a graphical development tool developed by IBM. The
software makes it possible to implement use cases for the Internet of Things with a
simple modular principle. The individual function blocks are related to each other by
dragging connections.
Fig. 5: Docker container
Legend
1 Arm processor
2 Linux operating system
3 Docker
4 Container with application
Function
Docker container
