11 TECHNICAL DATA
98
8027311 / V1-0/2022-04|SICK
OPERATING INSTRUCTIONS|TDC-E (Telematic Data Collector)
Subject to change without notice
Interfaces
GPS
Log
Electrical connection
✔
Satellite-based supplemental system L1 C/A: WAAS,
EGNOS, MSAS, GAGAN
GPS, GLONASS, BeiDo, Galileo
MCX
Modem data transmission
rate
✔,
4G
(≤ 150 Mbit/s), full 4G performance cannot be
guaranteed at operating temperatures above 60 °C.
Ethernet
Data transmission rate
Electrical connection
✔
(2)
10 Mbit/s ... 1,000 Mbit/s
RJ45
WLAN
Data transmission rate
Electrical connection
✔
(≤ 65 Mbit/s), single band 2.4 GHz
IEEE 802.11 b/g/n
WPAN
✔,
IEEE 802.15.1, IEEE 802.15.4, IEEE 802.15.3
Serial
Electrical connection
✔
, RS-232, RS-422, RS-485, SSI, 1-wire
Micro-Fit (20-pin)
CAN bus
Data transmission rate
Log
Electrical connection
✔
(2)
1 Mbit/s, adjustable
J1939, CANopen
Micro-Fit (20-pin)
USB
Electrical connection
✔
, USB2.0
USB 2.0 A male connector
Inputs/outputs
I/O 6 analog inputs (configurable, current and voltage),
6 digital inputs/outputs (configurable), 2 additional
digital inputs, 2 additional digital outputs
1)
Optical displays 3, LED, status indicators
Configuration interface REST-API
web interface
1)
Analog measurement of voltage (0 – 36 V) with accuracy of ± (0.2%+30 mV), current
(0 – 32 mA), with accuracy of ± (1%+0.1 mA), input resistance 27.5 kΩ typical for voltage mode,
100 Ω typical for current mode.
