Operating Instructions 8-5 M90 Fusion Splicer
Issue 02/97 Accessories
Installing / ex-
changing the
battery
Warning
This work may only be performed by appropriately qualified personnel.
Only the maintenance-free safety battery available as an optional extra may be in-
stalled.
Opening the
top panel
Warning
Switch off the splicer! Disconnect the power plug!
See section 7
Remove the bat-
tery retaining
angle
Loosen the self-locking nuts (1) and remove the battery retaining angle.
Removing the Battery Retaining Angle
