Function diagrams 05.05
8-122 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
Sheet Z120 SBP pulse encoder evaluation
8
7
564321
- Z120 -
X400
X401
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
+5/15V
u
&
<1>
<2>
<2>
<2>
<2>
1
0
2
0
1
&
U792 (1024)
n795
B7000
B7001
B7002
B7003
B0055
B0056
U796
n024.02
K0039
KK0036
K0038
U794 (500,0)
+ Vss
- Vss
CTRL +
CTRL - = M
Voltage level
U790.01: A/B, CTRL track
U790.02: Zero pulse
Supply voltage
U791 = 0: 5V
U791 = 1: 15V
Reference speed
50.0...6500.0
Encoder type
U793=0: A/B track
U793=1: Forward/reverse tracks
Number of lines
100...20000
Track A +
Track A -
Track B +
Track B -
Position
<1> 0=Enable position counter (KK0036)
1=Reset (KK0036:=0)
<2> The signals "coarse pulse 2" and "fine pulse 2"
are only routed to binectors B7002 and B7003
in the SIMOREG DC Master.
They have no other function.
Zero pulse +
Zero pulse -
Track A
Track B
Zero pulse
Control track
Overflow
Underflow
SBP pulse encoder evaluation
Power supply
Pulse encoder
Ground coarse/fine
Coarse pulse 1
Coarse pulse 2
Fine pulse 2
Coarse pulse 1
Coarse pulse 2
Fine pulse 2
Control track
Pulse encoder evaluation
Speed measurement
Speed actual value in rpm
Speed actual value
Reset
position counter
Position acquisition
value range:
8000 0000H to 7FFF FFFFH
