Function descriptions 05.05
9-66 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
6RA7095-4DV62 and 6RA7095-4KV62
Tp (s) Tp (s) Tp (s) Tp (s) Tp (s) Tp (s)
Ig (%) X=1.8 X=1.5 X=1.4 X=1.3 X=1.2 X=1.1
0 8.620 23.520 35.400 56.300 94.920 164.420
10 7.378 20.361 31.064 50.189 87.161 157.186
20 6.169 17.114 26.540 43.681 78.348 148.563
30 5.012 13.871 21.887 36.852 68.439 138.188
40 3.922 10.752 17.198 29.797 57.475 125.541 X t
an
(s)
50 2.910 7.889 12.663 22.639 45.671 109.901 1.1 274
60 1.992 5.385 8.571 15.623 33.425 90.316 1.2 128
70 1.197 3.281 5.173 9.344 21.245 65.970 1.3 65
80 0.559 1.596 2.535 4.520 10.275 38.038 1.4 37
90 0.107 0.428 0.709 1.302 2.929 11.665 1.5 23
94 0.062 0.195 0.311 0.533 1.179 4.610 1.8 8
98 0.022 0.070 0.112 0.192 0.421 1.613
100 0.002 0.008 0.012 0.021 0.043 0.115 t
ab
(s) = 493
6RA7095-4DV62 2000A/4Q 400V
6RA7095-4KV62 2000A/4Q 690V
0,1
1,0
10,0
100,0
1000,0
0 102030405060708090100
Base-load current as % of rated DC current
Overload period in s with cycle time of 300s
X=1,8
X=1,5
X=1,4
X=1,3
X=1,2
X=1,1
6RA7095-4DV62 2000A/4Q 400V
6RA7095-4KV62 2000A/4Q 690V
0
50
100
150
200
250
300
0 102030405060708090100
Base-load current as % of rated DC current
Overload period in s with cycle time of 300s
X=1,8
X=1,5
X=1,4
X=1,3
X=1,2
X=1,1
