Siemens 6RA7086-6KS22

05.05 Parameter list
SIEMENS AG 6RX1700-0AD76 11-147
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
Enable and setting of the PI controllers
U531
(2531)
*
S00
(B180...
B189)
Source for control signals (enable PI controller) [SW 1.8 and later]
0 = Binector B0000
1 = Binector B0001
etc.
i001: 0 = Disable controller PI controller 1
i002: 0 = Disable controller PI controller 2
...
i010: 0 = Disable controller PI controller 10
i011: 1 = Freeze I component PI controller 1
i012: 1 = Freeze I component PI controller 2
...
i020: 1 = Freeze I component PI controller 10
i021: 1 = Freeze output PI controller 1
i022: 1 = Freeze output PI controller 2
...
i030: 1 = Freeze output PI controller 10
i031: 1 = Freeze I component in pos.direction PI controller 1
i032: 1 = Freeze I component in pos.direction PI controller 2
...
i040: 1 = Freeze I component in pos.direction PI controller 10
i041: 1 = Freeze I component in neg.direction PI controller 1
i042: 1 = Freeze I component in neg.direction PI controller 2
...
i050: 1 = Stop I component in neg.direction PI controller 10
All binector numbers
1
Ind: 50
WE=0
Typ: L2
P052 = 3
P051 = 40
off-line
U532
(2532)
*
S00
(B180...
B189)
Source for control signals (set PI controller) [SW 1.8 and later]
0 = Binector B0000
1 = Binector B0001
etc.
i001: 0 = Set I component PI controller 1
i002: 0 = Set I component PI controller 2
...
i010: 0 = Set I component PI controller 10
i011: 0 = Set output PI controller 1
i012: 0 = Set output PI controller 2
...
i020: 0 = Set output PI controller 10
All binector numbers
1
Ind: 20
WE=0
Typ: L2
P052 = 3
P051 = 40
off-line
U533
(2533)
*
S00
(B180...
B189)
Source for Setting values [SW 1.8 and later]
0 = Connector K0000
1 = Connector K0001
etc.
i001: Setting value for I component PI controller 1
i002: Setting value for I component PI controller 2
...
i010: Setting value for I component PI controller 10
i011: Setting value for Output PI controller 1
i012: Setting value for Output PI controller 2
...
i020: Setting value for Output PI controller 10
All connector
numbers
1
Ind: 20
WE=0
Typ: L2
P052 = 3
P051 = 40
off-line
