05.05 Connections
Siemens AG 6RX1700-0AD76 6-9
SIMOREG DC Master Operating Instructions
X172
X173
X174
X175
X
R
X
S
X
T
X
P
XF1
XF2
X163
X164
X161
X171
X162
The customer connections must be routed above the electronics box.
Fig. 1c: Connecting shields on SIMOREG DC Master converters up to 850A
X171
X172
X173
X174
X175
XP
XR
XS
XT
Fig. 1d: Connecting shields on SIMOREG DC Master >850A
